Series W1C

Access Door

Standard Features

300 Lbs. Per Sq. Ft. Load Rating
(1464 Kg Per Sq. Meter Load Rating)
Extruded Aluminum Channel Frame
Single Leaf Construction
Auto-Lock T-316 Stainless Steel Hold Open Arm With Release Handle
T-316 Stainless Steel Hinges And Attaching Hardware
T-316 Stainless Steel Slam Lock With Removable Key
Stainless Steel Compression Spring Assist
Built-In EPDM Cushion/Gasket
Non-Ozone Depleting Bituminous Coating
Recessed Lifting Handle
Lifetime Guarantee

CUSTOMIZE YOUR QUOTE

Contact Email Enter Email

Required

Submitting your form now...

The server encountered an error. Please try again.

Form received! Thank you!

Customer Name Enter Name

Required

Company Enter Company

Required

Notes Enter Your Message

QTY. Quantity for W1C2424:

QTY. Quantity for W1C2430:

QTY. Quantity for W1C2436:

QTY. Quantity for W1C2442:

QTY. Quantity for W1C2448:

QTY. Quantity for W1C3030:

QTY. Quantity for W1C3036:

QTY. Quantity for W1C3042:

QTY. Quantity for W1C3048:

QTY. Quantity for W1C3054:

QTY. Quantity for W1C3060:

Contact Phone Number Enter Text

Required

Shipping Zip Code Enter Text

Required

QTY. Quantity for W1C3636:

QTY. Quantity for Custom Size (A):

QTY. Quantity for Custom Size (B):

Custom Size (A) - A DIM. Inches (MM): SIZE

Custom Size (B) - A DIM. Inches (MM): SIZE

Custom Size (A) - C DIM. Inches (MM): SIZE

Custom Size (B) - C DIM. Inches (MM): SIZE

QTY. Quantity for W1C3642:

QTY. Quantity for W1C3648:

QTY. Quantity for W1C3654:

QTY. Quantity for W1C3660:

QTY. Quantity for W1C3666:

QTY. Quantity for W1C3672:

QTY. Quantity for W1C4242:

Please ensure all Required fields are complete before submitting

N/A

Channel Frame - SERIES W
